Double Wall Corrugated Pipe Extrusion Line
Double Wall Corrugated Pipe Extrusion Line
Plastic Corrugated Pipe Production Line
PE Single Wall Corrugated Pipe Extrusion Making Machine / Double Wall Corrugated (DWC) Pipe Machine.
The Single Wall corrugated pipe line includes single screw extruder, extrusion mold, pipe corrugate calibration machine, double winder, etc.
The Double Wall Corrugated Pipe machine includes two set single screw extruders, DWC corrugated machine, cooling tank, cutting machine and stacker. The DWC pipe is mainly used for sewer pipe water drainage.
If you need this machine, please tell us the pipe diameter you want to produce, we will make the right offer for you.
The Single Wall corrugated pipe line includes single screw extruder, extrusion mold, pipe corrugate calibration machine, double winder, etc.
The Double Wall Corrugated Pipe machine includes two set single screw extruders, DWC corrugated machine, cooling tank, cutting machine and stacker. The DWC pipe is mainly used for sewer pipe water drainage.
If you need this machine, please tell us the pipe diameter you want to produce, we will make the right offer for you.
Products Description
The plastic corrugated pipe production line is mainly used to produce flexible corrugated pipe for electrical wire protection, theproduction raw material is PE/PP/PVC/PA granules.
The plastic corrugated pipe production line is mainly composed of vacum feeder, single screw extruder, die head, forming machine,forming modules and winder.
The plastic corrugated pipe production line is mainly composed of vacum feeder, single screw extruder, die head, forming machine,forming modules and winder.
Product Parameters
|
Single Wall Pipe Line
|
||||
|
Machine model
|
Pipe Diameter (mm)
|
Motor Power(Kw)
|
Speed (m/min)
|
|
|
SJ-45/30
|
16-32
|
11
|
1-10
|
|
|
SJ-50/30
|
16-40
|
15
|
1-12
|
|
|
SJ-65/30
|
16-63
|
22
|
1-12
|
|
|
HDPE double wall corrugated tube dwc pipe making machine series
|
|||||
|
Machine model
|
Pipe Diameter
|
Extruder model
|
Motor power
|
Production speed
|
Mold pairs
|
|
DWC-110
|
50-110mm
|
SJ65/33&65/30
|
45kw&30kw
|
3-4m/min
|
72pairs
|
|
DWC-160
|
75-160mm
|
SJ65/33&65/30
|
55kw&37kw
|
2-3.5m/min
|
72pairs
|
|
DWC-315
|
110-315mm
|
SJ75/33&65/33
|
90kw&55kw
|
2-5m/min
|
72pairs
|
